STAL 750 W 6000 l/h deep well pump up to 72 m

Manufacturer code: 10062050
Hillvert brand submersible pump easily pumps water from deep and narrow wells, wells, tanks or cisterns. The stainless steel housing has a diameter of just95 mm and is ideal for narrow wells. The 750-watt motor operates at 2850 rpm and provides a high flow rate of up to 6,000 l/h. The unit can be submerged to a depth of 50 m with a maximum head of m. The well pump is suitable for clean water up to 35deg C - just right for water supply. Hillvert focuses on durability. That's why the well pump's motor is hermetically sealed and protected from pressure and water. The stainless steel housing is resistant to corrosion and dirt. In addition, it reliably withstands even the heaviest loads.
Technical parameters:

• - Part number - 10062050
• - Item condition - New
• - Model - MSW-SPP44-075-50
• - Overall diameter - 95 mm / 3.75''
• - Filter - Yes
• - Insulation Class - B
• - IEC Protection Class - I
• - Color - Silver
• - Number of stages (pump impellers) - 10
• - Max. submergence depth under water - 50 m
• - Max. sand content in water [%] - 0.25
• - Maximum number of starts per hour - 50 h
• - Maximum input power - 1.5 kW
• - Maximum output power - 0.75 kW
• - Maximum water temperature - 35 deg C
• - Maximum head - 72 m
• - Maximum operating pressure - 7.35 Bar
• - Maximum water flow - 6 m³/h
• - Maximum particle size - 1.8 mm
• - Material - Stainless steel
• - Control methods - External starter box (750 W)
• - Voltage [V] - 230
• - Rated current - 5 A
• - Rated speed [rpm./min] - 2850
• - Water flow rate - 6000 l/h
• - Overcurrent - Yes
• - Power cord - 50 m
• - Cord specification - H07RN-F 3G1 mm²
• - IP rating - IP68
• - Mounting hole diameter - 100 mm
• - Water connection diameter - 1.25 in
• - Check valve - Yes
• - Weight - 16.85 kg
• - Shipping weight - 19.7 kg
• - Dimensions (DxSxW) - 83 x 9 x 9 cm
• - Shipping dimensions (DxSxW) - 123 x 24 x 12 cm

Included:

• - Submersible pump
• - User manual
